Investing in the construction of photovoltaic parking sheds can change the single role of traditional parking sheds. Photovoltaic parking sheds not only provide shade and rain protection for vehicles, but also generate electricity to bring benefits, achieving a win-win situation for both social and environmental benefits.

光伏車棚作為分布式光伏項目（或者作為其中的一部分），與充電樁、新能源電動汽車相結合，利用設在棚頂?shù)墓夥M件發電，通過充電裝置儲存到蓄電池中或直接供給電動車充電使用，自發自用，甚至可以余電上網。

As a distributed photovoltaic project (or as part of it), the photovoltaic car shed is combined with charging piles and new energy electric vehicles to generate electricity using photovoltaic modules located on the roof of the shed. It is stored in batteries through charging devices or directly supplied to electric vehicles for charging, self generated and self used, and can even be connected to the grid with surplus electricity.

交谷太陽能作為國內早開發光伏車棚系統的集成商，在國內外擁有眾多的案例，產品遠銷非洲、中東、東南亞、部分歐美地區。已經為馬耳他、以色列、坦桑尼亞、贊比亞等的駐外使館提供了太陽能光伏車棚方案和系統設備。

As the earliest integrator in China to develop photovoltaic car shed systems, Jiaogu Solar has numerous cases both domestically and internationally, and its products are exported to Africa, the Middle East, Southeast Asia, and some European and American regions. We have provided solar photovoltaic shed solutions and system equipment for embassies abroad from countries such as Malta, Israel, Tanzania, and Zambia.

作為經濟環保時尚的建筑一體化配套工程，太陽能光伏車棚有哪些特點呢？

What are the characteristics of solar photovoltaic car sheds, as an economic, environmentally friendly and fashionable integrated building supporting project?

一、光伏車棚的特點

1、 Characteristics of photovoltaic car sheds

1.吸熱性好

1. Good heat absorption

2.成本低廉、安裝便捷、靈活性好

2. Low cost, convenient installation, and good flexibility

3.充分利用原有場地，提供綠色環保的能源

3. Fully utilize the existing site to provide green and environmentally friendly energy

二、光伏車棚的種類

2、 Types of photovoltaic car sheds

① 按場所：家用、公司、商場、大型停車場

① By location: household, company, shopping mall, large parking lot

② 按風格：經典、簡約、現代、復古、炫酷

② By style: classic, minimalist, modern, retro, cool

③ 按停車類別：電瓶車/自行車、轎車、大巴/公交車

③ By parking category: electric vehicles/bicycles, sedans, buses/buses

④ 按功能：普通車棚、智慧車棚（配套充電樁、儲能系統等）

④ By function: ordinary car shed, smart car shed (equipped with charging stations, energy storage systems, etc.)

⑤ 按立柱形式：C型、H型、 L型、M型、N型、T型、V型、W型、X型、Y型、Ⅳ型、Ⅵ型

⑤ According to the column form: C type, H type, L type, M type, N type, T type, V type, W type, X type, Y type, IV type, VI type

⑥ 按立柱數量：單立柱、雙立柱、多立柱

⑥ According to the number of columns: single column, double column, multiple columns

⑦ 按支架類別：鋼結構、鋁合金、柔性大跨距支架

⑦ By bracket category: steel structure, aluminum alloy, flexible large-span bracket

⑧ 按支架表面處理：熱鍍鋅、噴漆

⑧ Surface treatment according to bracket: hot-dip galvanizing, painting

⑨ 按防水性：密封防水、普通不防水

⑨ According to waterproof properties: sealed waterproof, ordinary non waterproof

⑩ 按組件：晶硅組件、雙波組件、薄膜組件

⑩ By component: crystalline silicon component, dual wave component, thin film component

按車位數：1車位、2車位、3車位、多車位（大跨距）

By number of parking spaces: 1 parking space, 2 parking spaces, 3 parking spaces, multiple parking spaces (large span)

按排數：單排車位、雙排車位

According to the number of rows: single row parking spaces, double row parking spaces

三、太陽能光伏車棚系統組成

3、 Composition of solar photovoltaic car shed system

它主要由支架系統、電池組件陣列、照明及控制逆變系統、充電裝置系統和防雷及接地系統組成。支架系統主要包括支撐立柱、固接在支撐立柱之間的斜梁、接在斜梁上用于支撐太陽電池組件陣列的檁條及固定電池組件陣列的緊固件等。

It is mainly composed of support system, battery module array, lighting and control inverter system, charging device system, lightning protection and earthing system. The support system mainly includes support columns, inclined beams fixed between the support columns, purlins connected to the inclined beams to support the solar cell module array, and fasteners to fix the battery module array.

每個車棚下面，都有個匯流箱，車棚頂端的太陽能電板，就是通過這里將吸收的電量統一收納，再經過傳輸至逆變器將直流電變?yōu)榻涣麟?，即可輸送至電網內，然后完成發電。

Under each car shed, there is a combiner box, and the solar panel at the top of the car shed collects the absorbed electricity uniformly through this box. Then, it is transmitted to the inverter to convert direct current into alternating current, which can be transmitted to the power grid and complete power generation.
