集中式光伏支架陣列排布對發電量和投入成本影響比較大的,所以關于它的陣列排布設計是一件非常重要的事情,在這里河北碩標新能源作為光伏支架生產廠家給大家分一下,在進行集中式光伏支架陣列排布需要考慮的因素。
The layout of centralized photovoltaic bracket arrays has a significant impact on power generation and investment costs, so its array layout design is a very important matter. Here, Hebei Shuo Biao New Energy, as a photovoltaic bracket manufacturer, will share with you the factors that need to be considered when arranging centralized photovoltaic bracket arrays.
集中式光伏支架陣列排布需要考慮很多方面的因素,需要結合發電量、現場地形、占地面積、日常檢修維護、成本控制等諸多因素;一套好的陣列排布設計方案,需要占地面積蕞小、使用線纜少,這樣的設計方案不僅可以控制成本,而且還可以降低線纜耗損,提高發電量。
The layout of centralized photovoltaic bracket arrays needs to consider many factors, including power generation, on-site terrain, floor area, daily maintenance, cost control, and other factors; A good array layout design scheme requires a small footprint and minimal use of cables. This design scheme not only controls costs, but also reduces cable consumption and increases power generation.
集中式光伏支架陣列排布主要考慮的因素:
The main considerations for the layout of centralized photovoltaic bracket arrays are:
1、方位角的選擇

1. Selection of azimuth angle
光伏支架陣列垂直面與正南方向的夾角。
The angle between the vertical plane of the photovoltaic bracket array and the due south direction.
2、傾斜角的選擇
2. Selection of inclination angle
光伏支架陣列平面與水平地面的夾角。
The angle between the plane of the photovoltaic bracket array and the horizontal ground.
3、光伏陣列間距的選擇
3. Selection of photovoltaic array spacing
光伏支架每個陣列的間距。
The spacing between each array of photovoltaic brackets.
4、單排或多排的選擇
4. Selection of single or multiple rows
光伏支架每個陣列安裝光伏板的排數。
The number of rows of photovoltaic panels installed in each array of photovoltaic brackets.
5、光伏陣列匯流方案選擇
5. Selection of photovoltaic array convergence scheme
一般情況下每20塊組件成為一個組串,每16個組串安裝一個匯流節點。
In general, every 20 components become a string, and every 16 strings are equipped with a bus node.
