1、太陽能光伏發電原理
1. Principles of Solar Photovoltaic Power Generation
光生伏打效應在液體和固體物質中都會發生,但是只有固體(尤其是半導體PN結器件)在太陽光照射下的光電轉換效率較高。利用光生伏打效應原理制成晶體硅太陽能電池,可將太陽的光能直接轉換成為電能。太陽能光伏發電的能量轉換器是太陽能電池,又稱光伏電池,是太陽能光伏發電系統的基礎和核心器件。太陽能轉換成為電能的過程主要包括3個步驟:
Photovoltaic effect can occur in both liquid and solid materials, but only solid (especially semiconductor PN junction devices) have higher Solar-cell efficiency under sunlight. The crystalline silicon solar cell is made by using the principle of Photovoltaic effect, which can directly convert the solar energy into electric energy. The energy converter of solar photovoltaic power generation is solar cells, also known as photovoltaic cells, which are the foundation and core components of solar photovoltaic power generation systems. The process of converting solar energy into electrical energy mainly includes three steps:
(1)太陽能電池吸收一定能量的光子后,半導體內產生電子一空穴對,稱為“光生載流子”,兩者的電極性相反,電子帶負電,空穴帶正電。
(1) After solar cells absorb photons of a certain amount of energy, electron hole pairs are generated in semiconductors, known as "photo generated charge carriers". The polarity of the two is opposite, with electrons negatively charged and holes positively charged.
(2)電極性相反的光生載流子被半導體PN結所產生的靜電場分離開。
(2) Photogenerated charge carriers with opposite polarity are separated by the electrostatic field generated by the semiconductor PN junction.
(3)光生載流電子和空穴分別被太陽能電池的正、負極收集,并在外電路中產生電流,從而獲得電能。
(3) Photogenerated current carrying electrons and holes are collected by the positive and negative electrodes of the solar cell, respectively, and generate current in the external circuit to obtain electrical energy.
太陽能光伏發電原理如下圖所示。當光線照射太陽能電池表面時,一部分光子被硅材料吸收,光子的能量傳遞給硅原子,使電子發生躍遷,成為自由電子,在PN結兩側集聚形成電位差。當外部電路接通時,在該電壓的作用下,將會有電流流過外部電路產生一定的輸出功率。這個過程的實質是光子能量轉換成電能的過程。
The principle of solar photovoltaic power generation is shown in the following figure. When light shines on the surface of a solar cell, a portion of photons are absorbed by the silicon material, and the energy of the photons is transferred to the silicon atoms, causing electrons to undergo transitions and become free electrons, which gather on both sides of the PN junction to form a potential difference. When the external circuit is connected, under the action of this voltage, a current will flow through the external circuit to generate a certain output power. The essence of this process is the process of converting photon energy into electrical energy.

在太陽能發電系統中,系統的總效率η由太陽能電池組件的光電轉換效率、控制器效率、蓄電池效率、逆變器效率及負載的效率等決定。目前,太陽能電池的光電轉換效率只有17%左右。因此,提高太陽能電池組件的光電轉換效率、降低太陽能光伏發電系統的單位功率造價,是太陽能光伏發電產業化的重點和難點。自太陽能電池問世以來,晶體硅作為主要材料保持著統治地位。目前對硅太陽能電池轉換效率的研究,主要圍繞著加大吸能面(如采用雙面電池減小反射)、運用吸雜技術和鈍化工藝提高硅太陽能電池的轉換效率、電池超薄型化等方面。
In a solar power generation system, the overall efficiency of the system η It is determined by the Solar-cell efficiency of solar cell module, controller efficiency, battery efficiency, inverter efficiency and load efficiency. At present, the Solar-cell efficiency of solar cells is only about 17%. Therefore, improving the Solar-cell efficiency of solar cell modules and reducing the unit power cost of solar photovoltaic power generation system are the key and difficult points of the industrialization of solar photovoltaic power generation. Since the advent of solar cells, crystalline silicon has maintained a dominant position as the main material. At present, research on the conversion efficiency of silicon solar cells mainly focuses on increasing the energy absorbing surface (such as using double-sided cells to reduce reflection), using impurity absorption technology and passivation process to improve the conversion efficiency of silicon solar cells, and making the cells ultra-thin.
目前,太陽能光伏發電系統主要應用于以下3個大的方面。
Currently, solar photovoltaic power generation systems are mainly applied in the following three major areas.
(1)為無電場合提供電源,主要為廣大無電地區居民生活生產提供電力,為微波中繼站和移動電話基站提供電源等。
(1) To provide power for electric field free integration, mainly for the daily life and production of residents in areas without electricity, as well as for microwave relay stations and mobile phone base stations.
(2)太陽能日用電子產品,如各類太陽能充電器、太陽能路燈和太陽能草坪燈等。
(2) Solar daily electronic products, such as various solar chargers, solar street lights, and solar lawn lights.
(3)并網發電,即接入電網。我國光伏并網發電已經很成熟了,從2013年開始,出臺了一系列的光伏發電促進政策,鼓勵有條件的地區工商業和戶用、公共建筑等建設光伏發電設施。
(3) Grid connected power generation, i.e. connected to the national power grid. China's photovoltaic grid connected power generation has become very mature. Since 2013, the country has introduced a series of policies to promote photovoltaic power generation, encouraging the construction of photovoltaic power generation facilities for businesses, households, public buildings, and other areas where conditions permit.
