1. Overview of Photovoltaic Car Shed

光伏車棚，顧名思義就是將光伏和車棚頂結合起來，這是一種光伏與建筑相

Photovoltaic car shed, as the name suggests, is a combination of photovoltaic and car shed roof, which is a combination of photovoltaic and architecture

結合中為簡單的一種。它不但能實現傳統車棚的所有功能，還能給發電給業主

The simplest type of combination. It can not only achieve all the functions of traditional car sheds, but also generate electricity for homeowners

帶來收益。一般采用鋼結構支架，簡單、大方、時尚、美觀，且為清潔環保的新

Bringing benefits. Generally, steel structure brackets are used, which are simple, elegant, fashionable, and beautiful, and are clean and environmentally friendly

能源，有效緩解社會的環境和能源壓力。

Energy, effectively alleviating social environmental and energy pressures.

2.  光伏車棚的特點

2. Characteristics of photovoltaic car sheds

建設光伏車棚，可以減少城市的用電壓力利用車棚的閑置面積，建設光伏車棚，光伏車棚發的電除供給車輛使用外，多余的電量還可以賣給，從而減緩城市的用電壓力。建設光伏車棚，節能的同時帶來收益資光伏車棚的建設，一改傳統車棚單一的作用，光伏車棚不僅能夠給車輛遮陽避雨，同時還可以發電帶來收益，實現社會效益和環境效益的雙贏。充分利用原有場地，提供綠色環保的能源光伏車棚是車棚建筑與光伏發電技術的完美結合，光伏車棚的節能環保模式

Building photovoltaic car sheds can reduce the electricity pressure in cities, utilize the idle area of the car sheds, and build photovoltaic car sheds. In addition to supplying vehicles with electricity, the excess electricity generated by photovoltaic car sheds can also be sold to the country, thereby alleviating the electricity pressure in cities. The construction of photovoltaic car sheds not only saves energy but also brings benefits. By replacing the single role of traditional car sheds, photovoltaic car sheds can not only provide shade and rain protection for vehicles, but also generate electricity and bring benefits, achieving a win-win situation for both social and environmental benefits. Fully utilizing the existing site and providing green and environmentally friendly energy, the photovoltaic car shed is a perfect combination of car shed construction and photovoltaic power generation technology, and the energy-saving and environmental protection mode of the photovoltaic car shed

充分響應了祖國的環境保護號召。減少碳排放，保護我們的生存家園。

Fully responded to the call for environmental protection from the motherland. Reduce carbon emissions and protect our survival home.

3.  光伏車棚的種類

3. Types of photovoltaic car sheds

按車位種類可分為雙車位車棚和多車位車棚。大多為模塊化設計，可單獨使用或多個組合，便于擴展，少則幾個車位，多則幾百個車位，靈活性強。

According to the type of parking space, it can be divided into dual parking sheds and multi parking sheds. Most of them are modular designs that can be used alone or in multiple combinations for easy expansion, ranging from a few parking spaces to several hundred, with strong flexibility.

按組件種類可分為普通光伏組件車棚和雙玻光伏組件車棚。采用普通的光伏組件，整體造價較低，投資回收期短。采用雙玻光伏組件，整體造價稍高，但整體造型更加美觀。

According to the type of component, it can be divided into ordinary photovoltaic module sheds and double glass photovoltaic module sheds. Using ordinary photovoltaic modules, the overall cost is low and the investment payback period is short. Adopting dual glass photovoltaic modules, the overall cost is slightly higher, but the overall shape is more beautiful.

4.  光伏車棚設計

4. Photovoltaic car shed design

4.1車棚結構外觀

4.1 Appearance of car shed structure

單車位光伏車棚結構

Single car photovoltaic shed structure

單車位光伏車棚設計結構一般分為倆種分別為圖1中的單支撐立柱結構設計，的雙支撐支柱結構設計；此方案直接采用太陽能電池板作為其屋面系統，太陽能電池板連接通過鋁合金壓塊方式固定，1塊太陽能電池板通常采用4個壓塊?？紤]到停車棚防水問題，可以在太陽能電池板之間增加泡沫棒并填充密封膠，而且在上部需要做彩鋼或者鋁合金蓋板，此種做法防水性能極佳，安全穩定，安裝方便。

The design structure of a single parking photovoltaic shed is generally divided into two types: the single support column structure design in Figure 1 and the double support column structure design in Figure 2; This plan directly uses solar panels as its roof system, and the solar panels are connected and fixed using aluminum alloy compression blocks. One solar panel usually uses four compression blocks. Considering the waterproof problem of the parking shed, foam rods can be added between the solar panels and filled with sealant, and color steel or aluminum alloy cover plates need to be made on the upper part. This method has excellent waterproof performance, safety and stability, and is easy to install.
