目前，隨著建筑面積總量的不斷上漲，BIPV將成為未來光伏應用的重要場景和建筑節能的重要方向之一。天能瓦將光伏系統與建筑深度整合，作為廠房屋頂新標準，尤其適用于企業廠房屋頂?shù)哪茉崔D(zhuǎn)型，讓普通建筑變得節能、綠色、環保。關于“天能瓦”，你究竟了解多少？

At present, with the continuous increase of the total building area, BIPV will become an important scenario for future photovoltaic applications and one of the important directions for building energy conservation. Tianneng Tile deeply integrates photovoltaic system with buildings as a new standard for plant roofs, which is especially applicable to the energy transformation of enterprise plant roofs, making ordinary buildings energy efficient, green and environmentally friendly. How much do you know about "Tiannengwa"?

防水性

Waterproof

為解決傳統彩鋼瓦在使用7-10年后，受自然條件影響出現屋頂銹蝕滲水的問題，天合藍天·天能瓦采用Q355高鋁鋅鋁鎂材質，防腐防銹鍍層150g/㎡，采用733瓦型，瓦間360度鎖邊，配合屋脊擋水板和大流量排水槽，排水高度74mm，杜絕漏水隱患。

In order to solve the problem of roof corrosion and water seepage caused by the influence of natural conditions after the traditional color steel tile has been used for 7-10 years, Trina Blue Sky · Tianneng tile is made of Q355 high aluminum zinc aluminum magnesium alloy, with anti-corrosive and antirust coating of 150g/㎡, 733 tile type, 360-degree locking between tiles, roof ridge water baffle and large flow drain, with a drainage height of 74mm, to eliminate the potential water leakage.

防火性

Fire resistance

由于傳統的彩鋼瓦無法保溫隔熱，會在雙層中間添加聚苯乙烯泡沫板，是一種非常易燃的有機合成物，燃燒迅速。天能瓦在組件與壓型鋼板構件整體使用A級防火材質，且通過CTC綠色建材認證和產品安全認證。

Since the traditional color steel tile cannot be insulated, polystyrene foam board will be added in the middle of the double layers, which is a very flammable organic compound and burns quickly. The Tianneng tile is made of Class A fire-proof material on the assembly and profiled steel plate components, and has passed the CTC green building materials certification and product safety certification.

抗風性

Wind resistance

傳統彩鋼瓦質地較輕，承重能力并不強，遇到大風等外界壓力容易被整列揭起，天能瓦采用榫卯結構相互扣接，受力面積更大，螺絲、壓塊雙保險，根據不同區域風壓條件及安裝形式提供三種支座選擇，具有組件、組件+瓦面、瓦面+屋頂三重保障，經風壓性能試驗測試，抗風壓可達13級。

The traditional colored steel tile is light in texture and has low load-bearing capacity. It is easy to be lifted up in the whole row when encountering external pressure such as strong wind. The Tianneng tile is interlocked with a tenon and tenon structure, with a larger stress area and double safety of screws and compression blocks. According to the wind pressure conditions and installation forms in different regions, three support options are provided, with triple protection of component, component+tile surface, tile surface+roof. After the wind pressure performance test, the wind pressure resistance can reach 13 levels.

高效率

high efficiency

天能瓦屋頂光伏系統解決方案使用快裝壓塊一次鎖緊到位，無需反復操作，僅需將組件插入壓緊即可。以安裝一塊組件為例，傳統安裝方式螺絲需要擰緊12次，而天能瓦快裝方式只需擰緊2次，經過安裝現場試驗認證，同時節省夾具、導軌安裝時間和勞動力成本，比傳統安裝方式效率提升100%。

The Tianneng tile roof photovoltaic system solution uses quick-fitting pressing blocks to lock in place at one time, without repeated operation, just insert and press the components. Taking the installation of a component as an example, the screws in the traditional installation method need to be tightened 12 times, while the Tianneng tile quick installation method only needs to be tightened 2 times. After the installation site test certification, it saves the installation time and labor costs of the fixture and guide rail, and improves the efficiency by 100% compared with the traditional installation method.

傳統彩鋼瓦屋頂安裝普通光伏系統，需安裝夾具、架設導軌，再鋪裝組件并用壓塊固定，材料多，工序多。天合藍天·天能瓦屋頂光伏系統解決方案通過參與建筑前端設計，采用通風、采光、運維通道一體化方案，適用于新建屋頂、彩鋼瓦翻新和屋頂覆蓋式安裝三種不同場景。

The installation of ordinary photovoltaic system on the traditional color steel tile roof requires the installation of clamps, the installation of guide rails, the installation of components and the fixing of pressure blocks. There are many materials and procedures. Trina Blue Sky · Tianneng Tile Roof Photovoltaic System Solution adopts the integration scheme of ventilation, lighting, operation and maintenance channels through participating in the front end design of the building, which is applicable to three different scenarios: new roof, color steel tile renovation and roof covering installation.

關于“天能瓦”，你究竟了解多少？以上就是為您講解的相關內容了，希望給你好的幫助，更多關于天能瓦的事項就來我們網站http://51lib.com.cn了解吧！

How much do you know about "Tiannengwa"? The above is the relevant content explained for you. I hope it can help you. For more information about Tiannengwa, please come to our website http://51lib.com.cn Understand!
