不同的屋頂安裝光伏組件的方法也不一樣，那么廠房屋頂光伏發電采用哪種安裝形式？常見的安裝方式有三種，下面小編為您講解。

The method of installing photovoltaic modules on different roofs is also different, so which installation form is used for photovoltaic power generation on the roof of the plant? There are three common installation methods, which are explained below.

1、坡屋頂安裝方式

1. Slope roof installation method

光伏板通過光伏支架順著屋面架空的安裝方式，同時所有的安裝規則要遵守通風散熱的要求。光伏電站陣列與屋頂屬于平行鋪設，光伏支架使用點陣式固定住主橫梁。

Photovoltaic panels are installed overhead along the roof through photovoltaic brackets, and all installation rules shall comply with the requirements of ventilation and heat dissipation. The array of photovoltaic power station is laid in parallel with the roof, and the photovoltaic support uses dot array to fix the main beam.

2、平屋頂安裝方式

2. Flat roof installation method

平屋頂?shù)慕Y(jié)構比坡屋頂還簡單些，在設計的時候找好光伏電站的適合的安裝傾角；其次，水泥屋頂?shù)姆浪畬右龊?，要使用防水卷材、水泥砂漿保護層、瓷磚等做好防水工作。

The structure of flat roof is simpler than that of pitched roof. When designing, find out the appropriate installation angle of photovoltaic power station; Secondly, the waterproof layer of the cement roof shall be well prepared, and waterproof coiled materials, cement mortar protective layer, ceramic tiles, etc. shall be used for waterproofing.

3、彩鋼屋頂安裝方式

3. Installation method of color steel roof

彩鋼瓦屋頂屬于工廠廠房屋頂使用比較多的屋頂結構了，其實彩鋼瓦屋頂安裝光伏電站與坡屋頂安裝方式區別不大，區別就是光伏電站底座安裝方式不一樣。如果在屋頂?shù)慕Y(jié)構承載力滿足的情況下，可以把傾角翹起來，加大安裝角度。

The color steel tile roof belongs to the roof structure that is used more frequently on the factory building roof. In fact, the color steel tile roof is not very different from the slope roof in terms of the installation mode of photovoltaic power station, but the installation mode of photovoltaic power station base is different. If the structural bearing capacity of the roof is satisfied, the tilt angle can be raised to increase the installation angle.

如果屋頂屬于彩鋼瓦型式，一般都考慮附加型，直接將組件平鋪在彩鋼瓦上，尤其是一般彩鋼瓦屋頂都沒有墻，采用平鋪的型式防風效果非常好，非常為安全；另外彩鋼瓦屋頂也有一定的傾角，雖然可能不是光伏發電對應的非常佳傾角，但加大傾角帶來的改造成本也是需要綜合考量的。

If the roof belongs to the color steel tile type, the additional type is generally considered, and the components are directly laid on the color steel tile. In particular, the color steel tile roof has no walls, so the flat type is very effective and safe; In addition, the color steel tile roof also has a certain inclination angle. Although it may not be a very good inclination angle for photovoltaic power generation, the transformation cost caused by increasing the inclination angle also needs to be considered comprehensively.

廠房屋頂光伏發電采用哪種安裝形式？我們從三個方面來講解了內容，您對此有什么疑惑就來我們網站http://51lib.com.cn進行咨詢吧！

What type of installation is used for photovoltaic power generation on the roof of the plant? We explained the content from three aspects. If you have any doubts about it, please come to our website http://51lib.com.cn Consult!
